Fe26 Ornamental Infill
Fortress® Fe26 steel railing is a pre-welded, easily customized and enhanced version of traditional fabricated iron railing.
Fe26 Traditional Infill
Pre-welded infill panelized system
FortressShield-coated utilizing advanced coating process to resist rust and corrosion
Top rail customization available
Use with wood, composite, vinyl or Fortress steel posts
Quick and easy installation
Fortress Fe26 steel railing panels are tested in accordance with ICC-ES™ AC273 & OBC/NBCC
Standard Colors
EASY INSTALLATION
Save time and money with options for pre-welded panelized infills and pre-attached brackets on posts.
SAFE & CODE COMPLIANT
Durable steel is tested to ensure peace of mind for your family and friends. Backed by a Limited Lifetime Warranty.
WEATHER RESISTANT
UV fade and moisture resistance locks in the beauty the first day and every day.
DESIGN CUSTOMIZATION
Find your perfect look with three top rail options, including a drink rail and numerous infill options. Add FortressAccents™ LED Lighting and safely enjoy your outdoor space anytime, day or night.
Specifications and Options
Traditional
28″ (711mm) | 32″ (813mm) CA only | 34″ (864mm) | 38″ (965mm) CA only | 40″ (1016mm)
6′ | Actual 69.5″ (1765mm)
8′ | Actual 93.5″ (2375mm)
10′ | Actual 117.5″ (2985mm)
Adjustable Traditional
28″ (711mm) | 32″ (813mm) CA only | 34″ (864mm) | 38″ (965mm) CA only | 40″ (1016mm)
6′ | Actual 72″ (1829mm)
8′ | Actual 93.5″ (2375mm)
Fe26 Posts & Brackets
Posts
Post Base Cover
Included in Post Box with 39.5″ (1003mm), 45.5″ (1156mm) and 55″ (1397mm) Post with base plate.
39.5″ (1003mm) Surface Mount | 39.5″ (1003mm) Post with Pre-Attached Brackets | 49″ (1245mm) Fascia Mount
Use 39.5″ (1003mm) Post with 34″ (864mm) Level Railing Infill Panel or with 28″ (711mm) Level Railing Infill Panel when using Accent Top Panel (ATP). Use 49″ (1245mm) Post for 34″ (1003mm) Stair Railing Infill Panel.
45.5″ (1156mm) Surface Mount | 45.5″ (1156mm) Post with Pre-Attached Brackets | 55″ (1397mm) Fascia Mount
Use 45.5″ (1156mm) Post with 40″ (1016mm) Level Railing Infill Panel or 34″ (864mm) Level Railing Panel when using Accent Top Panel (ATP). 34″ (864mm) Stair Railing Infill Panel can be used with 45.5″ (1159mm) Surface Mount Post. Use 40″ (1016mm) Level Railing Infill Panel with 45.5″ (1156mm) Post with Pre-Attached Bracket (2″/51mm bottom rail) for 42″ (1067mm) install.
55″ (1397mm) Surface Mount Post
Use with 40″ (1016mm) Stair Railing Infill Panel.
49″ (1245mm) Adjustable Stair Stringer Post can be used with any of FBP’s Level or Adjustable Steel Infill Panels when used in conjunction with c-channel. No welding required. For stair panel installation, use 55″ posts, Universal Brackets with angle adjusters, adjustable Collar Brackets or Simplified Stair Brackets.
Universal Bracket — Hidden Fasteners (Patented)
UB (Level)
04 (1″/25mm) | 05 (1.25″/32mm)
UB-ANG
04 (1″/25mm) | 05 (1.25″/32mm)
Add to Universal Bracket for Stair or Angle/Miter Application. Use UB05 when installing ATP with Fe26.
Collar Bracket — Traditional Fasteners
- CB (Level) — 04 (1″/25mm) | 05 (1.25″/32mm)
- CBS-ADJ (Angle/Miter) — 04 (1″/25mm)
- CB-ADJ (Stair) — 04 (1″/25mm)
Patio Bracket
For on-grade use only — 30″ (762mm) or less above ground.
- Patio Bracket Standard (Level)
- Patio Bracket ADJ — Stair or Angle/Miter applications
Fascia Mount Bracket
- Straight Bracket — 2″ (51mm) | 3″ (76mm)
- Inside Corner Bracket — 2″ (51mm) | 3″ (76mm)
- Outside Corner Bracket — 2″ (51mm) | 3″ (76mm)
Simplified Stair Bracket
For stair applications only. One package of 4 brackets is needed to install one stair panel.
SSB — 04 (1″/25mm) | 05 (1.25″/32mm)
Required for Horizontal Stair Railing panel applications (Axis & H-Series).
I-Support
Traditional, Axis & Pure View, Attachment for Fascia Mount, Cable Level, Cable Stair.
Follow local building codes for support requirements.
-
Fe26 Installation Guide Embedded Concrete Post
-
Fe26 Installation Guide Embedded Concrete Post (French)
-
Fe26 Installation Guide Embedded Concrete Post (Spanish)
-
FortressAccents™ Lighting 100W Premium Transformer Instructions
-
FortressAccents™ Lighting 60W Transformer Instructions (Trilingual)
-
FortressAccents™ Post Caps and LED Lighting
-
Stair Stringer Post Installation Guide
-
Stair Stringer Post Installation Guide (French)
-
Stair Stringer Post Installation Guide (Spanish)
Gates
Traditional Gate
34" (864mm), 40" (1016mm); 34.5" (876mm). Fits a standard 36" (914mm) opening.
Personalization
Knuckles
Use to add a unique look to your railing balusters. 5/8" Balusters only.
Ball Cap
Cap without lighting capability. 3" (76mm).
Posts & Brackets
Pressed Dome Cap
Cap without lighting capability. 2" (51mm) | 3" (76mm).
Uncategorized
Accent Top Panel
Actual 93" (2362mm) x 5" (127mm). 8' Ring Top, 8' Circle Top, 8' 3 Rail. Hinges, locks and latches are available.
Accent Top Rail
An Accent Top Rail (ATR) or drink rail is needed for all Al13 HOME™ panel installations. Round | Level: 6' | Actual 69.89" (1775mm), 8' | Actual 93.89" (2385mm), 16' | Actual 189.78" (4820mm). Round | Stair: 6' | Actual 79.375" (2016mm), 8' | Actual 100.875" (2562mm). Flat | Level: 6' | Actual 69.89" (1775mm), 8' | Actual 93.89" (2385mm), 16' | Actual 189.78" (4820mm). Flat | Stair: 6' | Actual 79.375" (2016mm), 8' | Actual 100.875" (2562mm).
Cap Rail Clip
Use to attach wood or composite board to top rail of panel.
LED Cap Light Kit
Cap with lighting capability. Light 1, 2, 3 or all 4 sides. Total of 4 lights.
LED Glow Light Kit
Cap with lighting capability. Available in 2" (51mm), 3" (76mm), 3.5" (89mm), 4" (102mm), 5" (127mm) and 6" (152mm).
Gate Uprights
For use with Fe26 Traditional Infill Panel. 34" (864mm), 40" (1016mm). Maximum overall width 48" (1219mm).
Gate Kit #2 Hinge Lock & Latch
Works with all Fe26, Fe26+, Al13 HOME and Al13 PLUS gates and gate uprights. Kit includes a Latch and 2 Hinges.
